Luna UI Documentation

AutoSaveView is a UIViewComponent that listens to GameSaveEvents.AutosaveStart / AutosaveComplete and animates a RadialLoading indicator. The arc spins in the loading color while saving; after the save completes (plus _hideDelay seconds), it snaps to a full circle in the complete color and hides a second later.

Setup

UXML — wrap a RadialLoading in a container named AutoSave:

html

<ui:VisualElement name="AutoSave">
    <luna:RadialLoading />
    <!-- optional label, icon, etc. -->
</ui:VisualElement>

Add the AutoSaveView component to the same GameObject as a PanelRenderer referencing this UXML. The component queries its elements in OnUILoaded(root) once the panel delivers its visual tree; while enabled, it auto-subscribes to GameSaveEvents and shows/hides on autosave activity.

The show USS class is toggled on the AutoSave container — animate visibility with USS transitions.

Inspector

Property	Type	Default	Description
`_hideDelay`	float	`1`	Seconds between save-complete and the completion snap (the indicator hides one second after the snap).
`_colorLoading`	Color	magenta	Arc color while saving.
`_colorComplete`	Color	green	Arc color when complete.

API

csharp

namespace CupkekGames.GameSave.Luna;

public class AutoSaveView : UIViewComponent

Methods

Method	Description
`OnSavingStart()`	Manually trigger the loading animation.
`OnSavingComplete()`	Manually trigger the complete animation + hide (after `_hideDelay`).

These handlers are wired to GameSaveEvents.AutosaveStart / AutosaveComplete automatically while the component is enabled. (The base UIViewComponent.Show() / Hide() methods still exist, but they drive the whole view's fade pipeline — not the autosave indicator.)
